Page 82 - MM TECHNO PLAST CATALOGUE

GMDSS GMDSS
® ®

GMDSS ICOM IC-GM1600E TB 560

Ÿ Superior low temperature characteristic Lithium battery pack Ÿ All-in-one portable AIS Class B device
Ÿ Large keypad with positive button action Ÿ Robust and compact design, easy installation
Ÿ Wide viewing angle LCD display Ÿ SRM transmission with SOS button
Ÿ Easy to operate even for unskilled operators Ÿ Typical operating time: 2 to 5 days
Ÿ One touch access to Channel 16 and call channel Ÿ Rechargeable battery included
Ÿ Highly visible yellow colored body
Ÿ Optional VOX headset for on-board use

IC-GM1600E

ICOM IC-GM600 TB 560

Ÿ VHF Mobile Transceivers
Ÿ Key Features:
Ÿ GMDSS VHF Radio with Class A DSC
Ÿ Meets MED “Wheel Mark” Requirements
Ÿ Meets ITU-R M.493-13 DSC TB - 520
Ÿ 4.3 inch Wide Viewing Angle Colour TFT LCD
Ÿ Provides Loud, Clear Audio
IC-GM600 Ÿ Intuitive User Interface Ÿ Small and lightweight design for easy lifejacket tting.
Ÿ DC-DC Converter PS-310 Ÿ High beam LED sending SOS message for clear indications.
Ÿ Typical 36 hours operating time.
Ÿ IP68 waterproof and 50m immersion depth.
GMDSS ICOM IC-GM800

Ÿ Reliable Performance for MF/HF Long Distance Communication
Ÿ Satisfies the SOLAS Carriage Requirements for a MF/HF Class A DSC
Radio
Ÿ Will Meet MED* “Wheel Mark” Requirements
Ÿ Large and High Contrast 4.3 inch Color TFT LCD with Day and Night Mode
Ÿ New Intuitive User Interface for Straightforward Operation TB - 520
IC-GM800 Ÿ IPX7 Waterproof Construction

SAMYUNG SNX-300 NAVTEX RECEIVER

PLOMO-500
Ÿ New model designed to IMO resolution and performance standards
effective from July 1st . 2005 (IMO Resolution MSC.148(77) ITU-R, M.540-2,
M.625-3, IEC-61162). Ÿ Innovative AIS technology, a replacement of Radar SART
Ÿ English channel (518KHz) & local channel (490KHz/4209.5KHz) are Ÿ Rugged and compact design
simultaneously receiving by two receivers built-in. Ÿ Buoyant / floatable and waterproof to 10m
Ÿ Receiving messages sets-up from outer navigational equipment and Ÿ Florescent backlight panel
channels. Ÿ SOS LED light
Ÿ Storage for over 200 advisory including 8,000 receiving letters in average Ÿ Easy to assemble and carry
length per channel. Ÿ Minimum operating life - 96 hours
Ÿ 50 messages permanently stored per channel and 72-hour-long storage of
SAMYUNG SNX-300 receiving letters.
Ÿ Automatic power blockage run by voltage protection circuit.
Ÿ Interfaced to INS (Integrated Navigation System) according to IEC-61162.
Ÿ Temperature : -15℃ to +55℃
Ÿ Humidity : 95% at 40℃
Ÿ Power supply : DC 10 ~ 36V, 12W@24V
Ÿ Size : 255W×163H×75D (mm) PLOMO-500
81 Ÿ Weight : 2.6kg 82
