night vision BINOCULAR
® ®

NIGHT VISION BINOCULAR

Model: NV400-B

NV400-B is a Digital Type Night Vision Binocular that provides you with
resolution equivalent to traditional Gen 2 type night vision binocular.
As it is a digital type night vision equipment, you can use it even during
day time without worrying that exposure to light will damage the
binocular (traditional night vision binoculars can be damaged easily
when turned on in bright environment).
Optical Performance :
Magnification (with digital zoom) - 3.5x ~ 7x
Digital Zoom - 2x
Objective Lens - 31mm
Angle Of View - 9°
Exit Pupil Distance - 30mm

NV400-B F# for Objective lens - 1.2
Viewing Range in daytime - 3mtr ~ ∞
Viewing Range in Darkness - Up to 400mtr
Working Voltage - 4.5v - 6.0v
Power Supply - 8x AA Batteries
Battery Life - 10 hours (with IR Off)

BINO 2 - WATERPROOF BINOCULARS 7X50 BAK4

The BAK 4 prisms create the sharpest and clearest images possible in a
binocular in this price range. All lenses are multi-coated for long lasting
protection.

The superior prisms combined with large lens diameters make these
binoculars very suitable for use in difficult conditions such as twilight or
bad weather.

Ÿ Robust Soft Touch case and ergonomic design
Ÿ Flexible rubber eye cups for ease of use with (sun) glasses
Ÿ Supplied with bag, floatation strap and lens caps
Ÿ Magnification: 7x50 mm
Ÿ Waterproof and fog-free (filled with nitrogen)
BINO - 2 Ÿ Fixed focus and central variable focus

MARINE BINOCULARS 7X50

The Porro Prism create the clearest images possible in a binocular in this
BINOCULARS The Porro Prism combined with large lens diameter 50mm make these
price range. All lenses are fully multi-coated for long lasting protection.

binoculars very suitable for use in difficult conditions such as twilight or
bad weather.

Ÿ Application : General Purpose, Marine
Ÿ Features : Fog proof, Waterproof, Water-Resistant
Ÿ Maximum Magnification : 7x
Ÿ Objective Lens Diameter : 50mm
Ÿ Lens Coating : Fully Multi-Coated
7x50 Ÿ Optical Design : Porro Prism
89 90
