MARINE COMPASS
SWITCH
® ®

NAVTECH COMPASS 35 BK- WH

Corrosion Resistant
Windshield or Dash Mount
Easy to ready precision dial D E C K
Colour - Black , white
NAVTECH COMPASS 35 BK- WH
HARDWARE

NAVTECH COMPASS 65 BK- WH

Illuminated Marine Compass
12 Volt Light for night time use.
Colour - Black, White

NAVTECH COMPASS 65 BK- WH PLASTIMO OFFSHORE 135 COMPASS

Designed for power boats
Boat Size: 9 Meters and above (30 FI +).
Graduated every 5°. Apparent dia 130mm
Heading numerals every 30 . unique articulated protective °
hood: built-in sliding cover composed of 3 telescopic parts.
Comes as standard in a flush mount version. Con be bracket
mounted with the addition of optional bracket
Magnetic cell mounted can shock absorbers. 1Lubber line.
Supplied as standard. 2 Bulbs. 12 VDC.
PLASTIMO OFFSHORE 135 COMPASS
PLASTIMO OFFSHORE 75 COMPASS

Plastimo offshore 75 compass
48833: Offshore 75 - Flush-mount, Black
48933: Offshore 75 - Mini-Binnacle. Charcoal Grey
Designed For Power Boats
Boat Size Room 5 To 9M (17 To 30 Ft) Graduated Every 5 . °
Apparent Di 70mm. a
Heading Numerals Every 30 Mounting°
Flush-mount: On A Horizontal Vertical Or Inclined Surface
PLASTIMO OFFSHORE 75 COMPASS Mini-Binnacle: Mounted On A Horizontal Surface Thanks To A
Clip-Plate (Supplied); Compass Is Removable.
Magnetic Cell Equipped With The Unique "Vibration Absorber"
System 1 Lubber
Line 1 Bulb 12 VDC

MARINE LIQUID MAGNETIC COMPASS

MODEL NO:
MMABS4 4” DIAL IN ABS CASE WITH 12/24 V DC LED:
MMMC6: 6” DIAL SPARE BOWL
The 4” Dial Compass is fitted in a specially developed ABS Case with
12/24 V DC LED lamp on top, fitted with anti-glare casing for night
illumination. The ABS Case prevents external magnetic effect on
the needle.

4" DIAL 6" DIAL
MODEL CARD DIA CERTIFICATION
MARINE COMPASS MMABS4 100mm MED is Directive 2014/90/EU
57 58
MMMC6 150mm MED is Directive 2014/90/EU
